LCM-900 - Compact Liquid Chiller Module - Part #FP00097
- SKU:
- FP00097
- Description:
- 137H X 192W X 224D mm, Compact Liquid Chiller Module
- Maximum Current:
- 15 A
- Maximum Power Draw:
- 360 W at 24 VDC
- Voltage:
- 22-27 VDC
- Coolant Temperature:
- -15 to 50°C (5 to 122°F)
- Storage Temperature:
- -20 to 50°C (-4 to 122°F)
- Compatible Fluids:
- Water, Water/Glycol Mix
- Refrigerant:
- R134a
- Weight:
- 3 kg (6.6 lbs)
- Dimensions:
- 137H X 192W X 224D mm (5.4H X 7.6W X 8.8D in)
- Orientation:
- Within 30° of vertical
137H X 192W X 224D mm, Compact Liquid Chiller Module
The LCM-900 from Wakefield Thermal is a compact, energy-efficient fluid cooling system designed for applications that require high-capacity cooling while minimizing footprint and power consumption. By providing the core refrigeration components in a compact, insulated unit, the LCM-900 seamlessly integrates into applications across various industries, including automotive, aerospace, communications, defense, electronics, and medical.
